Region Filling Algorithm | MATLAB Code without using bwfill | Digital Image Processing

clc clear all close all warning off %% %Take the Original Image a=[ 0 0 0 0 0 0 0 0 0 1 1 0 0 0 0 1 0 0 1 0 0 0 1 0 0 1 0 0 0 0 1 0 1 0 0 0 0 1 0 1 0 0 0 1 0 0 0 1 0 0 1 0 0 0 1 0 0 1 1 1 1 0 0 0 0 0 0 0 0 0]; imshow(a); %% %Defining the structuring element b=[0 1 0;1 1 1;0 1 0]; %% %Take the complement of the original Image acmp=~(a); %% %Deside the strat point of hole and make that 1 x=[0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0]; %% y=(imdilate(x,b) & acmp); %% while(~isequal(x,y)) x=y; y=(imdilate(x,b) & acmp); end y=y | a; subplot(1,2,1) imshow(a); title('Original Image'); subplot(1,2,2) imshow(y); title('Image after performing region filling operation');
