DC Electric Circuits 🌟 Norton's Theorem - Load Current & Voltage 💡 Calculations & Simulations EX1

In this video (Example 1), we will discuss the Norton's Theorem in DC Electric Circuits. We will apply the Norton's Theorem on a circuit having a DC voltage source and several resistors. We will demonstrate how you can use the Norton's Theorem to represent a complex circuit by a simple model (Norton Equivalent Circuit) having only one current source (Norton Current) in parallel with a resistor (Norton Resistance). We will apply this model to calculate the voltage and current for a load resistor. The calculations will be done step by step and we will verify these calculations in simulations using TINA-TI Spice. 🎯 Outline of this video: ⏩ 00:00:00 Introduction ⏩ 00:00:57 Problem Description 🌟 Calculations: ⏩ 00:01:45 Calculations - Step 1 (Remove the Load Resistor and Short the Output Nodes) ⏩ 00:02:05 Calculations - Step 2 (Determine the Norton Current) ⏩ 00:04:38 Calculations - Step 3 (Determine the Norton Resistance) ⏩ 00:05:54 Calculations - Step 4 (Form the Norton Equivalent Circuit using Norton Current and Norton Resistance) ⏩ 00:06:47 Calculations - Step 5 (Connect the Load Resistor to the Norton Equivalent Circuit) ⏩ 00:07:18 Calculations - Results ⏩ 00:08:21 Calculations - Summary 🌟 Simulations: ⏩ 00:08:33 Simulations - Results ⏩ 00:10:35 Simulations - Discussion in TINA-TI Spice 👉 For more DC Electric Circuits:    • DC Electric Circuits   ⭐ If you have questions or comments, please let me know. Help us to reach more people. Like and share this video. Subscribe to our channel: https://www.youtube.com/canbijles/?su... ⚡ CAN Education - Tutoring in Electrical Engineering, Analog Electronics, Power Electronics, Electric Circuits, Control Systems, and Math Courses ⭐ For questions, collaboration or consulting 👇 📧 can.mehmet.tr@gmail.com ☎️ +31616179479 🔗 https://whatsapp.com/channel/0029VajY... 🌐 https://www.canbijles.nl #norton #Theorem #Circuits #Current #Resistor #Source #Electric #Circuits #Mesh #Current #Voltage #Resistor #Source #analog #electriccircuits #meshanalysis #kirchhoff #kirchoffslaw #ohms_law #ohmslaw #ohm #volt #ampere #amperecircuitallaw
