CLOSED LOOP CONTROL OF THE PHASE SHIFTED FULL BRIDGE CONVERTER USING MATLAB SIMULINK P1

Phase shifted full bridge (PSFB) DC-DC converters are used frequently to step down high DC bus voltages and/or provide isolation in medium to high power applications like server power supplies, telecom rectifiers, battery charging systems, and renewable energy systems. Traditionally, micro-controllers have been restricted to only performing supervisory or communications tasks in these systems. With the availability of high performing micro-controller devices, it is now possible to use micro-controllers for closing control loops in these systems, in addition to handling the traditional micro-controller functions. The transition to digital power control means that functions that were previously implemented in hardware are now implemented in software. In addition to the flexibility this adds to the system, this simplifies the system considerably. These systems can implement advanced control strategies to optimally control the power stage under different conditions and also provide system level intelligence. PLL (Phase Locked Loop) USING MATLAB SIMULINK    • PLL (Phase Locked Loop) USING MATLAB SIMUL...   CLOSED LOOP CONTROL OF 3-∅ FRONT-END CONVERTER USING MATLAB SIMULINK    • CLOSED LOOP CONTROL OF 3-∅ FRONT-END CONVE...   CLOSED LOOP CONTROL OF PHASE SHIFTED FULL BRIDGE (PSFB) CONVERTER USING MATLAB SIMULINK ‪@EETECH91‬    • CLOSED LOOP CONTROL OF PHASE SHIFTED FULL ...
