Q6915(Window size:W1.5xH0.5m)(Turbine:8x7.5kw)shot blasting machine

1. Shot blasting machine (Q034zz): 8*7.5 kW; (Variable frequency motor, without independent fan) 2. Maximum sized scaffolding and formwork: 3.2 m (length) * 1.2 m (width) * 0.35 m (height) Metal wall thickness: 1.5-4 mm (mainly carbon steel) It can accommodate a fixed-width frame of 0.75 m, and an additional frame with a variable width between 0.3 m and 0.6 m. Considering a 5 cm gap between frames and on each side, the maximum total width of the equipment is approximately 1.35 m. 3. Shot blasting chamber opening (width*height): 1500 mm*500 mm; (rolled manganese 13, thickness 12mm) 4. Front and rear auxiliary chamber length: 2+2m (65Mn 6mm) Rainproof specified in the instruction manual 5. Shot receiving hopper: 3m; 6. Sealing: Polyurethane curtain; 7. Roller conveyor: Feeding roller: 3.2m + Exiting roller: 3.2m; (Φ76*400 mm) Enables forward and reverse rotation Wear-resistant sheath: Cast steel MN13 8. Shot chute: Iron (manufactured before shipment) 9. Conveying speed: 0.5-1m/min 10. Shot blowing system, manual blow gun: 2 sets 11. Pitless design, convenient for customers to move work positions later Equipment: Length: 12,400 mm; Width: 9,043 mm; Height: 6,161 mm mm; Loading height: 1300mm 12. Pre-assembled before shipment for easy customer self-installation; electrical components, cable trays, limit switches, and inspection components are all in place.
