How-To 2013 Honda Civic Deck Lid Spoiler Installation

Tools and Supplies Needed: phillips screwdriver, drill, eye protection, center punch, file, touch-up paint, felt-tip pen, tape, masking tape, heavy gloves, high-quality paste wax, ruler. 1. Open the trunk lid. If equipped remove the trunk lid trim panel. 2. Close the trunk lid. To prevent the metal shavings from falling onto the trunk floor, attach strips of tape to the trunk lid. 3. Place the template on the left side of the trunk lid, and align the template with the edge of the trunk lid as shown. Tape the template to the trunk lid with strips of masking tape. 4. Using a felt-tip pen, mark the trunk lid through the template at the two locations shown on the template. 5. Remove the template. 6. Turn the template over, and repeat steps 3 through 5 of the right side of the trunk lid. 7. Center-punch the four marks you made of the trunk lid. If using an automatic center punch, set it to the minimum setting. 8. While wearing eye protection, drill 8.5 mm holes at the center-punched marks with an 8.5 mm hole cutter. Drill perpendicular to the trunk lid. 9. Remove the tape installed in step 2. Remove all burrs and metal shavings with a file, and apply touch-up paint to the edges of holes. 10. Using two alcohol swabs, thoroughly clean the trunk lid where the trunk spoiler will attach. 11. Get the trunk spoiler and the four clips. Install the four clips to the trunk spoiler. 12. Peel back the tab tape from each adhesive strip, and tape the ends to the front surface of the trunk spoiler. 13. Align four clips in the spoiler with the holes in the trunk lid, and install the spoiler. Apply pressure tot he trunk spoiler over each clip until you hear a click. Do not apply excessive pressure. 14. Visually check that the clearance between the trunk lid is the same on both sides. If necessary, adjust the position of the trunk spoiler until there is equal spacing on each side. 15. While applying light pressure against the trunk spoiler, carefully remove the bottom adhesive backings. 16. Using your hand, firmly press the rear portion of the trunk spoiler against the trunk lid. 17. While applying light pressure against the trunk spoiler, carefully remove the two top center adhesive backings shown. 18. Using your hand, firmly press the top center portion of the trunk spoiler against the trunk lid. 19. While applying light pressure against the trunk spoiler, carefully remove the next two inboard adhesive backings down. 20. Using your hand, firmly press this portion of the trunk spoiler against the trunk lid. 21. While applying light pressure against the trunk spoiler, carefully remove the two outboard adhesive backings down. 22. Using your hand, firmly press this portion of the trunk spoiler against the trunk lid. 23. Applying light pressure against the trunk spoiler, carefully remove the two remaining adhesive backings. 24. Using your hand, firmly press the edge of the trunk spoiler against the trunk lid. 25. Using and rubber roller, apply firm pressure while rolling to set the adhesive especially at the ends. 26. Install trunk springs. www.ezhondaparts.com www.edvoyleshonda.com
