Cisco SD-WAN: Configure Service Insertion at DC Hubs (Service Chaining)

#cisco #ciscosdwan #ciscotech #sdwan #fortigate 00:00 Introduce and Steps configuration 02:16 Start Configure , make interface VPN 10 for Service Device at DC-Hub01 03:38 Enable Service Route at service VPN Template and then assign Interface connected Service Device into Device Template 06:50 Show OMP service at vSmart 08:32 Change next-hop of route in Hub-and-spoke Policy to Service Chaining. 12:13 configure Firewall as Service Chaining Device. 12:55 Tracert route to Check Traffic via Firewall or not 13:58 Diagnose packet in Firewall ----------------------- To configure Service Insertion, need: 1. Enable Service Route in device have service devices. 2. Apply Policy to Centralized policy and then active it in vsmart ! ------------------------- In my Lab, Firewall at DC Hubs is Service Device, traffic from remote site will be redirect to this Firewall and then being forwarded to destionation. Firewall is configured One Arm mode, and basic configuration. -------------------------- Topology: https://imgur.com/miqj1F3
