Three Phase Transformer complete design core, window, winding, space factor, specific loading, turns

describe step by step procedure to design a 250 KVA three phase distribution transformer. Describe design of core type transformer with rated KVA and calculate emf per turn first. From calculated emf per turn flux and core net cross section area is calculated. From iron area select suitable core section and design all step sizes from di of circum circle. window area is calculated from output equation and height and width ratio is optimized. Total frame design, centre to centre core limb distance, overall width, overall height all are calculated. The problem also design winding. Calculate number and size of conductors for both LV and HV and suggest type of cross section and layout with required insulation. Great practical approach. For notes link is below https://drive.google.com/drive/folder... https://drive.google.com/file/d/113VU... for notes use link below https://drive.google.com/drive/folder... This and other video on design have links as : Videos on AC machine armature winding design are also available on channel. Induction Motor Design Design of Induction motor 100kW for best pf and 70 HP for best overall performance    • Design of Induction Motor, 100 kW for best...   Design of 5 HP induction Motor    • Design of 5 HP Induction Motor, Main dimen...   Shape and numbers of slots stator and rotor of induction motor design    • Design of Induction Motor, shape and numbe...   Length of air gap between stator and rotor for Induction Motor Design    • Design of Induction Motor Length of Air Ga...   Specific electric and magnetic loading of Induction Motor Design    • Design of Induction Motor, Specific magnet...   Output equation of Induction Motor Design    • Design of Induction Motor | Output Equatio...   Construction of induction motor    • Induction Motor | Construction | Stator, R...   DC Machine Design Solved Examples 2 of DC machine    • DC Machine Design | Solved Example | Main ...   Solved Examples 1 of DC machine    • Design of DC Machine | Solved Numerical Ex...   Selection of number of poles of DC machine    • DC Machine Design | No. of poles | Frequen...   Specific magnetic and electric loading of DC machine    • DC Machine Design | Specific Loading in ou...   output equation of DC machine    • DC Machine Design | Output Equation | Main...   construction, working and speed control of DC motor    • Speed Control of DC motor   Transformer Design Solved example 3 of Transformer Design    • Transformer Design as ration of window to ...   Solved example 2 of Transformer Design    • Three Phase Transformer complete design co...   Solved example 1 of Transformer Design    • Transformer Design solved example single p...   Emf per turn of Transformer Design    • Emf per Turn in Transformer Design, core, ...   Specific magnetic and electric loading for Transformer Design    • Specific Loading and Frequency roll in tra...   output equation of Transformer Design    • Transformer Design Output Equation | emf p...   core and limb cross section of Transformer Design    • Transformer Core Cross Section Design | st...   transformer construction core -shell type    • Transformer Types Core and Shell   transformer construction    • Transformer Construction   For business inquiries : sdmpclasses@gmail.com
