Casting Tools And Equipment's | Pattern types | Manufacturing Processes |

In this video we have shown real life pictures of different foundry tools being used widely during casting, different types of patterns, sample video of sand preparation, recorded video of casting in foundry shop of our college. #foundrytools#casting#castingtools#pattern#castingequipments Shovel- A shovel consists of a square pan fitted with a wooden handle. It is used for mixing and for moving the sand from one place to another in the foundry. Riddle- A riddle has a standard wire mesh fixed into a circular or square wooden frame. It is used for cleaning the moulding sand. Rammer- A hand rammer is made of wood or metal. It is used for packing and ramming the sand for moulding. Slick- A slick is a double ended tool having a flat on one end and a spoon on the other. It is used for repairing and finishing the mould surfaces after the pattern is withdrawn. Lifter- A lifter is made of thin sections of steel of various width and lengths with one end bent at right angles. It is used for smoothing and cleaning out depressions in the mould. Swab- A simple swab has a small brush having long hemp fibres. A bulb swab has a rubber bulb to hold the water and a soft hair brush at the open end. It is used for moistening the sand around the age before the pattern is removed. Bellow- A hand operated bellow is used to blow loose particles of sand from cavities and surface of the mould. Trowel- It consists of a metal blade with a wooden handle. The small trowels of various shapes are used for finishing and repairing mould cavities as well as for smoothing over parting surface of the mould. Gate cutter- It is a U-shaped piece of thin sheet. It is used for cutting a shallow trough in the mould to act as a passage for the hot metal. Gaggers- These are iron rods bent at one end or both ends. These are used for reinforcement of sand in the top of the moulding box and to support hanging bodies of sand. Moulding Boxes (Flasks)- The sand moulds are prepared in a specially constructed boxes called flasks, which are open at the top and bottom. They are made in two parts, held in alignment by dowel pins. The top part is known as cope and the lower part is called as drag. If the flask is made in three parts, the intermediate part is called a cheek. These flasks can be made of either wood or metal. Moulding Machines: a) Jolt Machine: It is used for ramming of sand in the mould. This machine rams the sand harder at the pattern face with decreasing hardness towards the back of the mould. b) Squeezing machine: this machine rams the sand harder at the back of the mould and softer on the pattern face. It is very useful for shallow patterns. c) Jolt-squeeze machine: This machine produces uniform hardness of sand in the mould. d) Sand slingers: They are used for uniform packing of sand in the mould. e) Diaphragm moulding machine: It is used for uniform ramming and hardness of the sand in the flask. f) Stripping plate machine: It is used to draw the pattern from the mould. If this video seems to be helpful to you than subscribe to our channel for more updates and Share it to your friends. For full playlist of Queuing Theory click below at:    • Queueing theory   For full playlist of Operation Research click below at:    • Operation Research
