KOLBUS DA270 Casemaker Used

For Sale: Kolbus DA270 Casemaker with Round Corners DESCRIPTION Kolbus DA-270 Year 2004 Technical details: ‘Co-pilot’ system with touch screen for automatic size setting, menu guided make-ready and fault indication Central board magazine feeder with manual loading Central soft spine feeder with double reel holder for auto-splice and cutter for waste Magazine feeder of pre-cut cloth with miss control Mobile hot-melt gluing unit with pre-melter Heated glue application roller with scraper roller Cloth cylinder with grippers & exchangeable plates for rubber pad Counter shingle delivery with roller conveyor & table External glue application adjustment Glue viscosity device for automatic water supply control Pressing roller for crease-free cover to board application Single case request for operator set-up Variable DC drive Automatic lubrication Including accessories & manuals. Accessories: Round corner device Specification: Size of opened case, Max: 670 x 390 mm Min: 205 x 140 mm Centre strip width : 6 - 90 mm, thickness 1 – 4 mm Joint width : 4 - 15 mm Turn-in width, closed : 8 – 15 mm Output, variable : up to 65 cycles/min Floor space : L: 6200 x W: 3000 x H: 2,200 mm Electrical loading : 15 kW (3ph, 400V, 50 Hz) Air requirement: 33 Nm3/h @ 6 bar #kolbus #casemaker #DA270 #casemakerused
