fc302 Danfoss drive initialization parameter, factory default of Danfoss fc302 . скачать в хорошем качестве

fc302 Danfoss drive initialization parameter, factory default of Danfoss fc302 .

To factory reset a Danfoss VLT drive (FC 102/302), change parameter 14-22 Operation Mode to Initialization, press OK, and power cycle the drive. For many models, holding [Status] + [Main Menu] + [OK] while powering on also triggers a reset. For controllers like ERC 213, hold up/down arrows during startup. This method (initialization) clears most settings and resets the drive to default values: Navigate to Parameter 14-22 Operation Mode. Select Initialization. Press [OK]. Disconnect the mains supply and wait for the display to turn off. Reconnect the mains supply. The drive will now be reset. Alternative "3-Finger" Reset (FC 302/FC 102) Disconnect power and wait for the display to turn off. Press and hold [Status], [Main Menu], and [OK] simultaneously. Apply power to the drive while holding these buttons. Release the buttons after approx. 5 seconds or when the display flashes. Danfoss Controller/Thermostat Resets ERC 213/214 Controller: Power off, then hold the Up and Down arrows simultaneously while turning the power back on until "FAC" appears. Living Connect Radiator Thermostat: Remove the battery cover, remove one battery, then press and hold the middle button while reinserting the battery for 5 seconds until the screen goes dark.
