Turbo-Mist Hitch Options (Turbo-Steer and Clevis Hitch)

Clevis Hitch – 0:07 o Describes cover that is attached over the top of pillow block and drive shaft at the front of clevis hitch model sprayers. Mentions grease holes and their purpose. ▪ Pillow block bearings: grease yearly. 2 pumps of grease per bearing (do not over grease) ▪ U joint: grease daily. Grease should be pumped until it is visible. Turbo-Steer – 1:00 o Shows and demonstrates Turbo-Steerer option and swivel operation. Turbo-Steer Hook Up – 1:55 o Demonstration of hooking up Turbo-Steerer hitch to tractor. Turbo-Steer Chains – 2:35 o Demonstration installing lower Turbo Steerer safety chains to tractor. Turbo-Steer PTO Angle – 5:00 o Discusses how to correctly set PTO angle to maintain 4 degrees. o Ensure Tank is level during PTO setup. Turbo-Steer Service Points – 6:05 o Discusses greasing the PTO shaft (center grease port on PTO shaft– once a month, perform while the shaft is disconnected from the tractor) (front u joint cross–grease daily)(rear u joint cross-grease daily)(Slip Clutch – grease yearly) o Discusses greasing Turbo-Steer gearbox (Top grease port – monthly grease 6 to 7 pumps) o Location of Turbo-Steer breather ports shown (Remove to check oil level in gearbox) (Note, both gearbox’s top and bottom need to be checked for oil level as they operate independently) o Swivel Assembly – Castle nut can loosen over time (Several years). Shims available for purchase ▪ Two Grease ports on swivel assembly (Beneath gearbox) (grease yearly) o General overview of how power is transferred from PTO to sprayer drive shaft. ▪ Grease port on front driveshaft u joint – grease daily o Explanation on how to replace an agitation belt on a Turbo-Steer Turbo-Steer – Leveling Sprayer – 9:45 o Explanation of how to check sprayer and tractor are level after hooking up PTO and Turbo-Steerer hitch. o Troubleshooting tips to achieve level.
