YM2016 Metal Plate/ Steel Sheet CNC Drilling Machine for drilling thickness 100mm, bolt hole 50mm.

CNC Metal plate drilling machine is a high-efficiency plane drilling machine. It is consists of machine bed(worktable ), gantry frame , drilling power head, automatic chip removal and circulation cooling system, control system, longitudinal slide platform, hydraulic system, and a quick-change chuck. The processing area is divided into ABCD four processing areas, which can drill and load and unload workpieces at the same time, and can also program drilling processing files .High precision, high efficiency, high rigidity, high reliability, etc . Drilling 100mm thickness, with drill hole 12-50mm. Effective cutting range is 2000x1600mm of metal sheet/steel plate etc. Industry application : It widely used for steel structure ,bridge ,power communication towers , boiler brackets of thermal stations and other industries connecting plate , foundation plates ,end plates ,flanges ,structure plates ,and other parts drilling process. Features: 1- high work efficiency This machine adopts the form of fixed bed and mobile gantry. Workpieces are clamped by hydraulic clamps, and the operator is controlled by a foot switch, which is easy to operate and saves labor. Small workpieces can be clamped at the four corners of the worktable, which can significantly shorten the production preparation cycle and improve production efficiency. 2- This machine has 3 CNC axes, Each CNC axis is guided by precision linear rolling guide, AC motor + ball screw drive 3-High working reliability The upper computer automatically processes the starting and ending points of working feed , and can not only drill through holes, but also drill blind holes, stepped holes, and chamfered hole ends. It has high processing efficiency, high reliability, simple structure, and low maintenance costs. 4-Self-controlled stroke power head High-efficiency self-controlled stroke drilling power head ,no need manually set the drill length and workpiece thickness, and can automatically perform fast forward-industrial advance-rewind for easy operation 5-Circulating water cooling Forced water cooling for drill bit cooling 6-Automatic chip removal A chip remover is installed under the bed, which can automatically remove chips 7-Automatic lubrication system Reduce equipment wear and increase service life 8- less failures Main components ,such as ball screw , linear rolling guide , hydraulic parts , electrical system , servo motor and frequency converter are all of world famous which are more steady and credible. Mob/whatsApp: +86-156 8972 8766/ +86-151 5319 8239 E-mail: Jackzhang0309@gmail.com
