Vertical Bar Screen

The waiting point of the rake is at the top section of the Bar Screen. When a command to begin the cycle is received from the timer, the rake descends while the rake holder folding into the rake housing. When the rake reaches the screen it is automatically stopped by proximity switches on the drums, and the rake holder opens and integrates into the screen, after a few seconds the rake ascends automatically. When the rake reaches the upper section of the Bar Screen, the wiper removes the garbage and it falls through the funnel into the garbage container. At the end of the ascension process the rake is stopped by a proximity switch located on the top of the rails. The cycle timer begins to count the time until the next cycle. The work regime of the device can be changed by manually adjusting the timer in accordance with the flow regimes and the amount of garbage.
