Ram 4th Gen (2013+) Incandescent to 5th Gen LED Tail Light Harness Walkthrough

Here is a walk through video of the 4th gen Incandescent to 5th gen LED tail light conversion harness (Non-Blind a spot Monitoring) that I make. This harness adds in the missing fault sense and turn signal driver wiring so that the lights function 100% OEM as on the 5th gens once all the settings are activated with Alfaobd. Alfaobd Settings: CBC I/O: Connector E Pin 3/Connector F Pin 42: Rear Turn Lamp Output Present - YES CBC Features: Combined Rear Lighting Enabled - NO CBC Features: Single Element Tail Lamp - YES CBC Features: LED Reverse Lamps Present - YES CBC Features: LED Stop Lamps Present - YES CBC Features: LED Rear Turn Lamps Present - NO (make note this is No not Yes) CBC Features: LED Tail Lamps Present - YES CBC Config I/O Usage: Door Ajar Switch Signal Rear Left Usage (Lamp Diagnostics) - Left Rear Lamp Diagnostics CBC Config I/O Usage: Connector F Pin 31: Right Rear Lamp Diagnostics/Right Rear Door Ajar Switch Signal Usage - Right Rear Lamp Diagnostics
