Area Functions – Land Division & Measurements Software

With Area Functions commands, you can Represent Area in Multiple Area Units, Create Area Table by selecting Lot Numbers and Derive Area by drawing a line or by referring to the existing line. You can sort Polygons by Area, and Scale Polygon from Centroid. You can also derive the Area Table from Multiple Polygons. Read more: https://esurveying.net/land-division-... Hello everyone, Welcome to the video tutorial about How to use Area Functions in the Land Divisions and Measurements Software. • QAR command : The QAR command is used to Quickly Mark Area of a Polygon The area of the selected Polygon will be Marked. To execute the command, o Type ‘QAR’ at the command prompt and o Pick a Point to Mark the Area. The Area of the selected entity will be marked as shown. • REAR command : The REAR command is used to Represent areas in Multiple Area Units. The area of the selected Polygon will be represented in Different Measuring units. To execute the command, o Type ‘REAR’ at the command prompt and then o Select the Object to get Area. After executing the REAR command, the area of the selected polygon will be shown in multiple units. • DPAR command : The DPAR command is used to Derive the required Area by drawing a line. To execute the command, 1. Type ‘DPAR’ at the command prompt. 2. Select the Base Line 3. What is the Area required? : Enter the Area Required: say 1000 4. Select the Side: Pick a point to select the side The Required Area will be marked as shown. After executing the DPAR command, a new polygon will be created with the specified area. • MCEN command : The MCEN command is used to Mark the center of the selected Polygon. The center of the selected polygon will be marked. To execute the command, o Type ‘MCEN’ at the command prompt and o Select the Polygon The center of the selected Polygon will be marked as shown. • SPO command : The SPO command is used to Scale Polygon from a Point. To execute the command, o Type ‘SPO’ at the command prompt. o Select the Polyline o Type the Target Area: 2000 o Select the point to scale. The selected entity will be scaled to the new area as shown. • ASE command : The ASE command is used to Sort Polygons by Area. The polygons in the selected entity will be sorted as per Area. To execute the command, o Type ‘ASE’ at the command prompt. o Type the Maximum Area in Sq. Meters and then o Select polylines for the area. o Select entities. The polygons in the selected entity will be sorted as per Area of the polygon. The Colour of the polygon will change depending on the category of the polygon. After executing the ASE command, the selected polygon will be sorted as per Area as shown and the color of the polygon is changed. Thank you for watching this video. In this video, you have learned how to use Area Functions. In the next video, you will learn how to work with Triangle Related Commands. Read more: https://esurveying.net/land-division-...
