How To Repair A Damaged Shaft Using Machining Techniques

Shafts are commonly found in various industrial applications where rotational motion is required to transmit power or perform specific functions. These essential components can suffer issues such as wear and tear from vibration, rubbing, abrasive contaminants, and corrosion. In situations where it is impractical to strip a shaft, Belzona metallic polymers can repair in-situ, limiting the downtime and lost production costs without the risks that result from welding procedures. A step-by-step how-to guide: 00:00 - Introduction 00:21 - Undercutting the substrate by a minimum of 0.06 inches (approx. 1.6mm) 00:31 - Machining a rough thread profile to achieve a clean, rough bare metal 01:00 - Degreasing the prepared surface using Belzona 9111 or any other approved cleaner/degreaser 01:12 - Applying 6-8 wraps of tape to both sides of the repair area to act as a thickness gauge 01:52 - Using Belzona 1111 (Super Metal) – a two-part repair composite 02:07 - Mixing ratio by volume: 3 parts base to 1 part solidifier 02:17 - Mixing thoroughly until a uniform, streak-free color is achieved 02:30 - Applying Belzona 1111, forcing it down into the surface using a brush to avoid air entrapment 03:06 - Removing excess product and smoothing out the surface 03:26 - Removing the tape 03:48 - Allowing the product to fully cure 03:53 - Machining the repair down to within 0.005 inches (125 microns) of the desired profile 04:32 - Removing the final 0.002 inches (50-75 microns) using fine emery cloth #Belzona #Shaft #repair 🔔 Subscribe and turn on notifications, so you don't miss any videos: https://www.youtube.com/belzona?sub_c... 👋GET IN TOUCH: https://www.belzona.com/en/contact.aspx 📖READ OUR LATEST BLOG: https://blog.belzona.com/ 👍CONNECT WITH US: On LinkedIn -   / belzona   📸 FOLLOW US: On Instagram -   / belzonaglobal
