OrCAD X Capture How to Series Part 6 - Finishing Touches, Netlisting & Exporting the Design

Welcome to the OrCAD X Capture Tutorial Series with Adam Fuchs. In this series Adam will demonstrate how to create a complete schematic in a step-by-step process. In this video, Adam will demonstrate the final steps of schematic design, including how to export your design and netlisting for use with a PCB Editor. Learn more about OrCAD X: https://www.cadence.com/en_US/home/to... Subscribe to our Channel: https://shop.cadence.com/Ecom/?SKU=OR... If you would like to access the files for this project click here: https://www5.cadence.com/rs/070-BII-2... Disclaimer: This video may have been recorded prior to changes made to the product’s user interface, or the video may be based on an earlier release of the product. The concepts and workflows conveyed in this video still apply to the current release of the product. Follow us on social for the latest OrCAD X news! 👉 Follow Cadence PCB Design and Analysis on X:   / cadencesda    👉 Follow Cadence PCB Design and Analysis on LinkedIn:   / cadencesda   👉 Follow Cadence PCB Design and Analysis on Facebook:   / cadencesda    #OrCAD #PCBDesign #CadenceDesignSystems #SchematicCapture #orcadx 0:00 - Intro 1:00 - The Property Editor 3:43 - Editing properties of a single component 4:53 - The Part Manager 10:39 - Annotating the design 14:45 - Inter-sheet references 16:40 - Exporting to PCB with a Netlist 19:05 - Exporting a Netlist
