KiCad 6: Design Rules and Net Classes

In this short tutorial, I will show you how to set your design rules using PCBWay as an example. I will also add a new net class. PCBWay Capabilities: https://www.pcbway.com/capabilities.html OshPark Capabilities (Guide setting KiCad 5): https://docs.oshpark.com/design-tools... Key Moments 00:00 - Intro 00:30 - Go find the manufacturer's capabilities 01:01 - Set design rules constraints 01:49 - Add a new net class 03:14 - assign non-default net class to net 03:33 - re-route tracks 4:14 - goodbye and thanks for watching #KiCad6 #PCBDesign
