Building a Modern Power Supply for the Commodore Plus/4

Check out our sponsor https://www.pcbway.com for all your PCB needs, starting at $5. The foot-warmer brick-of-death power supply that came with this Plus/4 needs to be replaced. Urgently. Before it destroys the computer. These power supplies are notorious for failing, and when they do, the voltage regulator shorts its output to its input, sending lethal voltages to all the chips in the computer. But we can make a brand new one that's safe and reliable. And all it takes is a 9 volt transformer, a small 5 volt Mean Well, a bit of soldering, and some 3D printing. Oh, and an LED. Because you've got to have LEDs. BTW this build will work equally well with a C64 or C128, all you need is the appropriate plug for the computer. Obligatory warning: mains voltages can be lethal. Do not attempt this project unless you are comfortable working with mains voltage and know what you're doing. The mains here is 240V, yours may be different. If you'd like to help support this channel, please check out my Patreon. You can also make a one-off donation or use the channel Super Thanks. Patreon:   / timsretrocorner   Donate: https://www.paypal.com/donate/?hosted... Follow me on Mastodon: https://retrorewind.social/@trc Some other channels you should check out: 8BitRetroRefix: @8BitRetroReFix Retro4u: @Retro4u Josip Retro Bits: @JosipRetroBits Captain Commodore: @CaptainCommodore Retro Krazy: @RetroKrazy 00:00 - Introduction 01:48 - PCBWay 02:25 - The PSU Connector 03:10 - Plus/4, C64, or C128? 06:16 - What we’re gonna do 10:23 - Take the Cables Off the Old One 12:33 - Breaking and Entering 17:09 - Wiring up the Transformer 21:45 - Fitting the Mean Well 22:16 - Wiring up the Connectors 23:42 - Wiring the output of the transformer 26:20 - Swap Over the Fuse 26:55 - Add an LED 27:38 - First Test 29:12 - Hooking Up the LED 29:27 - LED 34:10 - Moment of Truth
