My Ben Eater inspired homemade 8-bit CPU - Part 2: Power & Clock

Hello again. Today, I take a look at the power connection and system clock of my homemade CPU. The clock module is described in great detail the following 4 of Ben Eater's videos:    • Astable 555 timer - 8-bit computer clock -...      • Monostable 555 timer - 8-bit computer cloc...      • Bistable 555 - 8-bit computer clock - part 3      • Clock logic - 8-bit computer clock - part 4   The 2 schematics I go through in the video are available here: https://github.com/jamesbates/jcpu/bl... https://github.com/jamesbates/jcpu/bl... Finally, the Texas Instruments document describing the various digital chip technologies, is available here: http://www.ti.com/lit/pdf/SDYU001 Enjoy this episode, and hopefully see you in the next one!
