Steel Sailboat Launch

Total Cost: $14525.00 US (I paid $9000 in boatyard rent for 3 years so the total cost to me to get the boat in the water was $23525.00. I only worked on the boat during the summer, so the actual boatyard time needed before launch was 6 months which would be $1500.) Total Cost Materials: $11880.00 US Volvo Penta MD2B Diesel Engine with Transmission: $1000 US Parts (something not built by me): $425 Total Cost Tools: $1220.00 US Common items such as hammers and extension cords not included in the cost. Cost of 14 pieces 5'x10' 11 gauge mild steel sheets: $1738.00 US (including delivery) Cost of 6 pieces 5' x 10' 14 gauge mild steel sheets: $515.00 (free delivery) Cost of 70 pieces 1/8" x 1/2" x 20' flat bar: $196.00 (free delivery) Cost of 6 pieces 1/2" x 0.49" x 20' round tube: $32.00 (free delivery) 180 pounds of flux core welding wire: $1550 200 quantity 4" diameter metal cutting wheels: $100 Primer for painting (Rustoleum Industrial Choice 6100): $270 Paint (Duralux Marine Paint Enamel - 22 gallons): $890 Paint Thinner (16 gallons): $366 Cement Mix (10 bags, 60 pounds each): $40 100 quantity 30 grit 4" diameter sanding discs: $67 100 pieces Douglas Fir 1 1/2" x 3 1/2" x 8': $500 1750 Guard Dog Exterior Screws: $100 35 pieces of 20 foot long 3/4" x 3/4" x 1/8 steel angle: $310 700 M8-1.25 lock nuts: $150 700 Washers: $28.00 Die for M8-1.25 threads: $10.00 14 pieces of 1 meter long M8-1.25 grade 8.8 threaded rod: $200 5 pieces 4'x8'x3/4" CDX Plywood: $190 Drill Bits: $20 7 Gallons Boiled Linseed Oil: $178 Brads: $13 Lexan: 4'x8' x 1/4": $300 Acrylic: 2 pieces 4'x8'x 1/4" (with $80 delivery): $500 3/8" 4x8 CDX Plywood 15 Pieces: $337 Lewmar Delta Fast Set 35 lb 22 kg anchor: $75 Volvo Penta MD2B Diesel Engine: $1000 Sink: Free White Fir Tree 36' long: Free Plastic Sheet to Cover Mast: $20 Propeller (Left Hand 12"Dia 14 Pitch), 3/4" Shaft, Coupler: $110 PSS Dripless Shaft Seal: $120 Nitrile Rubber 12"x12"x1/8": $10 1 Pc 11 Gauge 5'x10' & 3 Pcs 13 Gauge 10'x4' Steel Sheet: $500 Canvas 9.3 Oz 60 yds x 60": $250 Thread 1500 yds 40 wt: $30 28 Needles Size 16: $30 Coal Tar Epoxy 5 Gallons + Xylene 1 Gallon + Shipping: $500 Fiberglass Resin: $50 Battery: $120 Morse Throttle and Gear Controller: $50 110 feet anchor rode + 50 feet anchor chain: Free Roofing tar 8.3 gallons: $110 2 Quantity 240 Watt Solar Panels: $110 434 18650 Lithium Ion batteries: $1300 Indoor/Outdoor Carpet: $100 Hardware: $100 Concrete for Ballast: $100 I already had the Lincoln welder which I purchased for $400 over ten years ago. Makita grinder was about $60 over ten years ago. Air Compressor was about $400 over 15 years ago. Paint Gun set was about $100 over ten years ago. Engine hoist from 15 years ago $200. Three quantity 8000 pound winches about $60 ($20 each). Other items not listed as costs were free.
