Mounting Tutorial: Harmony XB4/ZB4 22 mm Pushbutton & Contacts — Allied Electronics & Automation

Shop Allied: https://www.alliedelec.com/switches/p... Tutorial for installing a Schneider Electric 22 mm Harmony XB4/ZB4 metal operator pushbutton and mounting the contact block The modular Harmony XB4 range of 22 mm metal control and signaling units combines simplicity of installation, efficiency, modern design, flexibility, and robustness to meet most industrial applications. Consisting of a snap-fit head and body that’s tightened with a single screw, these units feature an ingenious locking system that allows for mounting that’s both easy and secure. The Harmony XB4 offering is available as complete products or separate components for customer assembly. Customize your pushbutton with a complete selection of accessories, including solutions for harsh-environment applications where exposure to high-pressure cleaning, dust, and extreme temperatures is an everyday occurrence. Features: Combined Functions: Contact + Illuminated Functionality Complete Products or Sub-Assemblies for User Assembly Connection: Screw Clamp Terminals, Plug-in Connectors, FASTON Connectors, Spring Clamp Terminals Robust and Strong Design that Securely and Easily Connects Together Mount Device by a Single Locking Screw (Anti-Rotation) Low-Load Electrical Contact and High Power Shakeproof Connection Screws Eliminates Periodic Retightening Only One Installer Required
