“INSTALLATION MUST ALWAYS ADHERE TO LOCAL PLUMBING CODES AND REQUIREMENTS. CHECK LOCAL PLUMBING CODES FOR GUIDELINES.” INSTALLATION 1. Find suitable place close to a water source for unit. Remove wall bracket from packaging, place level on wall and mark (3) mounting holes. Drill (3) 5/16” holes and install anchors in wall. Secure wall bracket to wall with screws and washers provided. NOTE: The distance from the top of the wall bracket to the top of the cabinet is 1/8”. 2. Place the cabinet onto the wall bracket aligning the tabs with the slots in the top of the cabinet. Also ensure the central snap on top of the wall bracket engages the cabinet. Mark the wall using the (2) lower holes, as guides, then remove cabinet from wall. Drill (2) 5/16” holes and install anchors in wall. 3. Connect water supply hose of at least 3/8” ID to water inlet swivel. (Minimum 25 PSI pressure, with water running, is required for proper operation. Maximum Pressure 85 PSI, Maximum water Temperature 120° F.) 4. Place the cabinet back onto the wall bracket (see #2) and secure the bottom of the cabinet to the wall with the screws provided. NOTE: IT IS REQUIRED THAT THE BOTTOM (2) SCREWS BE INSTALLED. 5. Remove the medallion cover from the unit by pushing inward on the two snap features located inside near the bottom of the medallion and rotate upwards. These snaps can be accessed by unlocking and opening the doors (See Page 3). 6. Select metering tips (up to four) for each selector valve (See next two sections.) Push each tip firmly into a separate hose barb extending from the selector valve. A tip with no hole (clear plastic) can be used to block any valve port not being used for chemical. (This may be used for dispensing water only.) 7. Cut supply tube provided into separate supply tubes for each product dispensed. Use “Y” fittings to connect both high and low flow eductor to a single container. Supply tubes should reach from hos barb on eductor select valve to the bottom of container for easy replacement of chemical. (See diagram page 3.) Prepare a tube for each barb of the select valve. Supply tube routing to lower containers should pass through the circular notch in the shelf back. NOTE: ARROW ON IN-LINE CHECK VALVES SHOULD BE POINTED TOWARD THE EDUCTOR. 8. A short discharge tube is used with the 1.0 GPM eductor; minimum tube length is 8 inches (20cm) for proper operation. Longer tubes (4 feet) are used with a 3.5 GPM eductor. Do not remove the flooding rings from inside the tubes. Install hose hook on longer tube to allow discharge tube to conveniently hang from dispenser when not in use. 9. Replace medallion cover. Insert the upper medallion tabs into the cabinet slots and swing down to engage lower medallion snaps on the inside of the cabinet. Ensure selector knobs are properly aligned. (See Diagram Page 3). YOUR PRODUCT IS NOW READY TO USE THANK YOU FOR CHOOSING HYDRO FOR A COPY OF THE FULL INSTALLATION MANUAL OR FOR FURTHER INFORMATION, PLEASE VISIT https://WWW.HYDROSYSTEMSCO.COM LinkedIn: / hydro-systems-company #HydroSystems #chemicaldispensingequipment #proportioningequipment
