Krones Contiroll 720-18 Roll Feed Hot Melt Glue Labeler

Unit is currently set up for a 5 oz PET bottle and is rated to run 24 - 35,000 bph depending on the bottle and label size. Overall dims 8'Lx4'Wx81''H. The Contiroll labelling station incorporates a label feed roller with cut control, cutting unit, gluing unit, and a vacuum-assisted gripper cylinder for the label transfer to the container. The label feed roller, as well as the gluing unit and vacuum-assisted gripper cylinder are driven by computer-controlled servo-motors. The gluing station can be exchanged enabling the use of different hotmelt types which are adjusted to the respective label material. The entire labelling station is designed to allow easy access from all sides.Large-capacity label reels minimize the operator workload significantly. Without a machine stop, the operator splices the end of the first reel with the beginning of the new reel. Thus, the need to thread the label web into the machine is eliminated. A cutting table is mounted at the labelling station to facilitate this task. Clockwise rotation with dual labeling stations. The Contiroll automatically applies wrap-around labels to round, oval, rectangular, square and polygon containers.,The krones Contiroll provides highly marketable, appealing labelling possibilities to a wide range of industries: from beverages and food, all the way to cosmetics and chemicals. It is capable of handling low-cost label papers as well as a wide range of film labels. for a label height of (30 150 mm). Can handle Bottle Sizes from 50 MM to 150mm diam. - http://www.smbsales.com/category?id=L...
