HOW TO SETUP AND CONFIGURE MERCURY LP1502 INTELLIGENT CONTROLLER | CHANGE IP ADDRESS | HOST COMM

The LP1502 intelligent controller provides decision making, event reporting, and database storage for the Mercury hardware platform. Two reader interfaces provide control for two physical barriers. The LP1502 communicates with the host via on-board 10-BaseT/100Base-TX Ethernet port or the Micro USB port (2.0) with an optional Micro USB to Ethernet adapter. Each reader port can accommodate a reader that utilizes TTL (D1/D0, Clock/Data), F/2F (standard or supervised) or 2-wire RS-485 device signaling (OSDP reader for example) and also provides tri-state LED control, and buzzer control (one wire LED mode only). Four Form-C relay outputs may be used for door strike control or alarm signaling. Eight inputs are provided that may be used for monitoring the door contacts, exit push buttons and alarm contacts. Input circuits may be configured as unsupervised or supervised. The LP1502 requires 12 to 24 Vdc for power.
