Install & Configure FreeRadius To Use MariaDB With DaloRadius Web Interface in Linux | Nehra Classes

Install and configure freeradius to use mariadb database (also for managing freeradius, we install daloRADIUS web interface). === 1- Install and setup mariadb To install mariadb, we create mariadb repository file and install required packages. here we install mariadb 10.5: vim /etc/yum.repos.d/mariadb.repo then put the following content in it: [mariadb] name = MariaDB baseurl = http://yum.mariadb.org/10.5/centos7-a... gpgkey=https://yum.mariadb.org/RPM-GPG-KEY-M... gpgcheck=1 now install mariadb: yum install mariadb-server mariadb-client then start mariadb service: systemctl start mariadb systemctl enable mariadb then do initial mariadb setup: mysql_secure_installation now we should create a user and database for freeradius in mariadb: Note: change “radiuspassword” with your desired password. mysql -u root -p CREATE DATABASE radius; GRANT ALL ON radius.* TO radius@localhost IDENTIFIED BY "radiuspassword"; FLUSH PRIVILEGES; quit; 2- Install apache and php for a managing freeradius through daloRADIUS web interface we need to install apache and php: yum install https://dl.fedoraproject.org/pub/epel... yum install yum-utils -y yum install http://rpms.remirepo.net/enterprise/r... yum-config-manager --enable remi-php73 yum install php php-common php-opcache php-mcrypt php-cli php-gd php-curl php-mysqlnd php-pear php-pear-DB then install apache: yum install httpd 3- Install and configure freeradius vim /etc/yum.repos.d/base.repo [base] name=CentOS-7 - Base mirrorlist=http://mirrorlist.centos.org/?release... #baseurl=http://mirror.centos.org/centos/7/os/... gpgcheck=1 gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-CentOS-7 yum install freeradius freeradius-utils freeradius-mysql freeradius-perl php-pear then we import freeradius schema: mysql -u root -p radius ( /etc/raddb/mods-config/sql/main/mysql/schema.sql and create a soft link to available mods: ln -s /etc/raddb/mods-available/sql /etc/raddb/mods-enabled/sql ok. now open etc/raddb/mods-available/sql and make change to be like the following: vim /etc/raddb/mods-available/sql sql { driver = "rlm_sql_mysql" dialect = "mysql" Connection info: server = "localhost" port = 3306 login = "radius" password = "radiuspassword" Database table configuration for everything except Oracle radius_db = "radius" } read_clients = yes client_table = "nas" then open /etc/raddb/clients.conf and change ipaddr and proto to be same as the following: ipaddr = * proto = tcp 4- Install and configure daloRADIUS now we install and configure daloRADIUS. its package is available in github. so download it and extract: wget https://github.com/lirantal/daloradiu... unzip master.zip mv daloradius-master/ daloradius cd daloradius now import daloRadius tables into database: mysql -u root -p radius ( contrib/db/fr2-mysql-daloradius-and-freeradius.sql mysql -u root -p radius ( contrib/db/mysql-daloradius.sql then move its directory to apache root document: cd .. mv daloradius /var/www/html/ change owner of daloRadius and set proper selinux policy: chown -R apache:apache /var/www/html/daloradius/ chmod 664 /var/www/html/daloradius/library/daloradius.conf.php restorecon -R /var/www/html/daloradius/ now open daloRadius config file and set the following parameters: vim /var/www/html/daloradius/library/daloradius.conf.php $configValues['CONFIG_DB_USER'] = 'radius'; $configValues['CONFIG_DB_PASS'] = 'radiuspassword'; $configValues['CONFIG_DB_NAME'] = 'radius'; 5- Configure firewall we need to open radius and web port. so issue these commands: firewall-cmd --permanent --add-port=1812/tcp firewall-cmd --permanent --add-port=1812/udp firewall-cmd --permanent --add-port=1813/tcp firewall-cmd --permanent --add-port=1813/udp firewall-cmd --permanent --add-port=80/tcp then reload firewall: firewall-cmd --reload 6- Start services In rare circumstances, selinux policy manager may be crashed when we start freeradius server. so first update some selinux packages: yum update setools checkpolicy policycoreutils now freeradius and daloRadius installation and configurations has been done. last thing is to start services: systemctl start radiusd.service systemctl restart mariadb.service systemctl restart httpd systemctl enable radiusd.service systemctl enable mariadb.service systemctl enable httpd then in your browser, point to this address: (remember to change IP address with your own) http://localhost/daloradius/login.php default username and password of dolaRadius is: Username: administrator Password: radius === If you like our hard work then do subscribe to our channel & turn on the bell notification for latest updates. === Yum Server RHEL 7:    • Configure Local Yum Repository in RHEL 7 (...   === ©COPYRIGHT. ALL RIGHTS RESERVED.
