AC Type 2 Surge Protective Device SPD assembling

AC Class C, Type 2 Surge Protective Device SPD assembling https://lsp.global/type-2-spd/ Type 2 Surge Protector Device SPD SLP40 series are generally installed in sub-distribution or machine control cabinets. Thanks to unique trigger release, effectively solve the isolation and extinguishing arc. 00:00 How to assemble a Type 2 SPD? 00:04 Place the circuit board into the base of the surge protector. 00:08 Insert the trigger spring and transmission rod. 00:13 Insert the metal parts and internal busbars. 00:18 Insert into the terminal block. 00:23 Close the top and bottom covers of the base. 00:32 Installing din-rail buckle. 00:38 Base assembly completed. 00:44 Insert the built-in spring. 00:48 Insert the arc extinguishing partition plate. 00:51 Insert the metal fixture used for fixation. 00:55 Insert metal electrode. 01:02 Selecting the appropriate MOV (Metal Oxide Varistor). 01:06 Insert the MOV into the inner shell. 01:10 Place the semi-finished product into the welding fixture. 01:24 Choose the correct low-temperature solder for welding. 01:33 Remove the semi-finished product from the welding fixture and check the MOV again. 01:42 Laser print on the surge protective device. 01:45 The outer shell closes with the inner shell. 01:56 Insert the pluggable module into the base. 02:03 Recheck the finished product. 02:07 Place the SPD, instruction manual, and floating switch terminal into the paper box. 02:28 Pack the product in double corrugated boxes. ---------------------------------------------------------------------------------------------------------------------------------------------------- Since 2010, LSP has been dedicated to designing and manufacturing surge protective devices protecting installations from transient overvoltages that result from switching events and lightning strikes. ---------------------------------------------------------------------------------------------------------------------------------------------------- Wenzhou Arrester Electric Co., Ltd. Email: info@lsp.global Website: https://lsp.global Address: 5th FL, No. 888 Liujiang Road, Liushi, Yueqing 325604 Zhejiang, China
