extruder screw and barrel manufacturing machine soni machines e.K скачать в хорошем качестве

extruder screw and barrel manufacturing machine soni machines e.K

extruder screw and barrel manufacturing machine CNC Milling Machine/Extruder Screws (Thread and Gear Milling Machine) Manufacturer: Wanderer Type: GF 34 CNC Year of Manufacture: 1991 4-Axis Path Control Siemens Sinumerik 3 M (GA4) with electronic Handwheel, with RF Radial Milling Head for machining extruder screws with climb milling unit, automatic Chip conveyor, coolant system with 1 fixed steady rest, 2 clamping steady rests, 2 bushing jigs, 1 chuck, RF milling head, safety guard with sliding doors, operating key, machine manuals, control documentation, etc., Main drive 20 kW DC Maximum workpiece diameter 600 mm Milling length 3000 mm Thread pitch 1 – 9999 mm Workpiece diameter over support 160 – 320 mm Spindle bore 120 mm Number of teeth min/max 4 – 100 Tool holder ISO 50 Infinitely variable longitudinal feeds 1 – 5000 mm/min Workpiece weight 2000 kg Electrical specifications – voltage/frequency 380 / 50 V/Hz Total power requirement 50 kW. Machine weight: approx. 10,000 kg Mit freundlichen grüßen / best regards Chandra soni Soni machines e.K Oewerwischenweg 01 18146 Rostock Germany Tel. +49 3818089234 Mobil +49 1627683411 Fax +493818089264 Email: info@sonimachines.de http://www.sonimachines.de Tel.: 01627683411
