Example 3.6 Heat Loss Through Composite Wall | Thermal Resistance Method | Heat Transfer Problem Sol

   • Effect of Fouling on Overall Heat Transfer...   In this video, we solve a heat transfer problem involving heat loss through a composite wall using the thermal resistance method. The wall consists of brick, plaster, and rigid foam layers with convection on both sides. We calculate the total thermal resistance and determine the heat transfer rate from indoor (20°C) to outdoor (−10°C) conditions. What you will learn: How to calculate thermal resistance of composite walls Conduction and convection resistances in heat transfer Step-by-step solution for engineering exams (BSc/BS/Mechanical/Heat Transfer) Real-life application of heat loss in building insulation Given Data: Brick, plaster, and rigid foam layers Convection coefficients (h₁ = 10 W/m²·K, h₂ = 25 W/m²·K) Indoor & outdoor temperatures: 20°C and −10°C Perfect for mechanical engineering students, thermodynamics learners, and GATE / FE exam preparation. 📌 Watch till the end for full numerical solution and final heat loss answer! 📌 Don’t forget to Like, Comment & Subscribe for more Heat Transfer problems! #HeatTransfer #CompositeWall #ThermalResistance #EngineeringThermodynamics #MechanicalEngineering #CFD #Insulation #Conduction #Convection #SolvedProblem #EducationShop
