Elettronika MIZAR300 - How to Replace the Final Transistor

This FM MIZAR300 Transistor replacement tutorial was brought to you by Elettronika Group TOOLS NEEDED: Flat Head & Phillips Screwdriver Heatsink Paste Soldering Iron & Tin Pick & Hook set tools STEP BY STEP INSTRUCTIONS: STEP-1: Remove the upper lead STEP-2: Remove the RF cavity lead STEP-3: Remove the transistor source screws STEP-4: Remove the termistor (R21 on AMP) STEP-5: Remove the transistor gate resistor (R20 & R23) & transformer (T1) terminal See full steps in http://elettronika.com Disclaimer: This step by step video is only for general knoledge purposes. With this video we do not intent to authorized anyone to repair any of our units, this must be performed by a qualified engineer. Before you intent to perform any labor in any of our Elettronika units you must be authorized by the engineering department. Any work perform without consent and authorization of Elettronika Group will cancel any valid warranty and we won't be responsable for any mayor or minor damage cause for unauthorized works in our units. CONTACT US English : http://elettronika.com/contact-englis... Español : http://elettronika.com/contact-spanis... TECHNICAL SUPPORT Complete Technical Support in English: http://elettronika.com/technical-supp... Soporte Tecnico Completo en Español : http://elettronika.com/technical-supp... Share Us, Like Us, and Follow Us Instagram: @Elettronika Twitter : @Elettronika Facebook :   / elettronika-america-321073284602250   Thank You for watching our videos.
