Drafting Standards — Layers, Linetypes, and Dimensions | CAD 101 – AutoCAD

Welcome back to CAD 101 – AutoCAD. In this lesson, we move beyond simply creating geometry and start applying proper drafting standards. You’ll learn how to: • Create and manage professional layer structures • Apply correct linetypes (continuous, center, dashed) • Control dimension styles and decimal precision • Fully define a part without dimensioning hidden lines • Build clean front, top, and right-side views • Improve overall drawing readability and layout This assignment reinforces one of the most important concepts in engineering graphics: A drawing is not just shapes — it’s communication. By the end of this video, your work should look less like practice… and more like engineering. If you're following the full CAD 101 sequence, make sure you're working through the playlist in order. Each episode builds directly on the previous one. More structured CAD lessons and real-world project builds coming soon. Let’s build something real. — Drip King Productions 👑 00:00 Intro – From Geometry to Drafting Standards 00:29 Assignment Overview & Requirements 02:14 Required Layers, Colors, and Linetypes 05:40 Creating Layers in AutoCAD 08:48 Front View Construction 16:07 Adding Hidden Lines & Center Lines 17:06 Building the Right-Side View 24:45 Building the Top View 34:39 Applying Dimensions (2 Decimal Format) 45:24 Improving Dimension Layout & Clean-Up 50:31 Outro – Engineering vs Practice
