DAEWOO - IKEGAI A20x60 PRECISION TOOL ROOM LATHE REF

Daewoo-Ikegai Precision Tool Room Engine Lathe Model No. A20x60" Serial No. 150105 1979 Catalog Specifications: 20" Swing Over Bed Ways 15.5" Swing Over Cross Slide 60" Distance Between Centers 3" Hole Thru Spindle 10.625" Cross Slide Travel 5.875" Compound Slide Travel 7.5" Tailstock Spindle Travel, 2-Speed No. 5 MT Tailstock Spindle Nose Taper 18 - 2000 RPM Spindle Speeds .035 - .05 IPR, Course Feed Rates (24) .022 - .031 IPR, Normal Feed Rates (24) .0015 - .02 IPR, Fine Feed Rates (24) 80 - 9/16 TPI, Inch Threading Range 0.5 - 64 mm/P, Metric Threading Range .25 - 16 Module Threading Range 136" x 70" Floor Space Required 5,600 Lbs. Approx. Weight Equipped With: Longitudinal Feed Precision Ball Screw Drive Southwest Industries Trav-A-Dial on Longitudinal Travel Aloris Type CA Quick Change Tool Holder (6) Various Aloris Inserts Hardened and Ground Bed Ways (3) Heavy Duty Adjustable Carriage Stops Spindle Inching Mode 12-1/2" 3-Jaw Rohm Chuck 12" 4-Jaw Buck Chuck 16" Adapter Plate 15" Adapter Plate 3-Point Steady Rest 2-Speed Tailstock (2) Extra Sets of Hard Top Jaws (9) Extra Sets of Soft Top Jaws Jacobs Drill Chuck Chuck Guard Dead Center Live Center Work Light Wrenches Tool Box Coolant 10-HP Spindle Motor Drive 220/440/3/60 Excellent Condition
