Milltronics VM3018IL IMTS 2022 Demo | CNC Mill | Inline Spindle

Full demo from IMTS 2022 Chicago on our VM3018IL performance machining center. The Milltronics VM3018IL has 30″ x 18″ x 22″ travels and a 34″ x 18″ table that supports 3,140 lbs table weight at full speed. The VM3018IL has a 24 HP 12,000 RPM BIG-PLUS spindle. Build a quote at https://www.milltronics.com VM3018IL Specs CAPACITY Travels 30 x 18 x 22 in Table Working Surface 34 x 18 in Max. Weight on Table 30140 lbs Table T-Slots .71 in SPINDLE Spindle Taper BIG-PLUS® ISO No. 40 Spindle Speed (Max.) 12000 RPM Spindle Power (Max.) 24/15 HP Spindle Torque (Max.) 84 ft-lbs Spindle to Nose 6-28 in AUTOMATIC TOOL CHANGER Tool Shank CT40 Retention Knob MAS 60 Tool Capacity / Type 30 / Double Arm Max. Tool Diameter 3.15 in Max. Tool Length 11.8 in Max. Tool Weight 15.4 lbs MOTION Rapid Traverse Rate 1200/1000 IPM GENERAL DETAILS Machine Weight 10700 lbs Machine Height 118.5 in Footprint 85.8 x 124.1 in (123.3 in with conveyor) Nominal Operating (W x D) Power Requirement 27 KVA / 67 Amps Voltage Requirement 208-240 Volts / 3 Phase #cncmill #milltronics #imts2022 #cnc #vm3018il #machiningcenter #imts
