IMT A70 Drilling in CFA Version 600 mm diameter

IMT A70 DRILLING in CFA (CONTINUOUS FLIGHT AUGER) Version 600 mm diameter IMT, a global leader in the manufacture of drill rigs and a brand which has always been synonymous with quality and reliability in the pursuit of satisfying market demand, is pleased to INTRODUCE the versatile A70 Piling and Drilling Rig. This unit is unique in its simplicity and flexibility of use, while also perfectly maintaining sturdiness and productivity. While being the most compact piling rig in its class, the A70 drill rig is suitable for the use in several different configurations, with very simple procedures for the conversion from one version to another. The machine was designed for very arduous applications as, thanks to its compact dimensions , powerful winch and rotary it allows to perform very fast working cycles in small job sites. Its heavy duty variable gauge undercarriage guarantees optimal stability in various working conditions and configurations. Drilling capability and specifications in CFA Technology: Crowd System Pushing force kN 35 Pulling force kN 300 Max push / pull speed m / min 35 Rotary stroke mm 11000 Main winch cable diameter mm 20 Drilling depth maximum w/o auger extension m 10,5 Drilling depth maximum w auger extensions m 14,5 Auxiliary winch pull force kN 30 Auxiliary winch speed diameter m/min 35 Auxiliary winch cable diameter mm 12 Pile max diameter mm 750 Operating Weight without auger t (metric) 24
