QuickField Webinar: Capacitance Calculations: Part 1/3

Part 1/3 More webinars, free demo version, sample simulations at www.quickfield.com. Capacitance calculation with QuickField. This free webinar was held at www.quickfield.com on April 3, 2011. Capacitors, cables, transmission lines (both power and signal) design and analysis require capacitance calculation. During this webinar you will learn how to effectively apply QuickField simulations for capacitance calculation. Part 1/3. Capacitance definition. The capacitance is ability of a conductor to store the charge in electric field. The capacitance of a conductor can be calculated as a ratio of conductor's charge to the conductor's potential. Capacitance of the sphere. The analytical equation. QuickField simulation. Electrostatic problem type. Boundary. Labels of geometrical objects. Properties of labeled objects. Building mesh and solving the problem. Capacitance wizard to calculate capacitance. Wizard offers two approaches of calculation capacitance -- via charge or via energy.
