Molflow webinar - Create geometry with built-in tools

One way to set up your geometry in Molflow is to create it from scratch. While not a CAD tool, it has basic editing features that allow you to create simple systems. https://molflow.web.cern.ch 00:14 - Problem description 1:45 - Starting with an empty geometry 3:53 - Create a circle and extrude it to a pipe 7:43 - Create a larger diameter circle at end of pipe 11:25 - Create difference of two circles 13:20 - Adding vertical pumping ports 14:30 - Rotating a circle (using an axis) 15:10 - Rotating a circle (using 2 vertices) 16:23 - Move a circle by fixed offset 16:55 - Move a circle up to an existing facet 18:40 - Mirroring a pipe to a plane 19:03 - Fixing a 0-area facet with the Collapse command 20:43 - Building T intersections between pipes 22:35 - Fixing the T intersection by scaling down vertical pipe 25:48 - Clear isolated vertices
