SolarEdge EV Charger Commissioning | International

This video provides a step-by-step guide on commissioning the SolarEdge EV Charger. In this video, you will learn: What's required for commissioning: You'll need the EV Charger already mounted and wired, a quick guide, possibly gloves, a flat screwdriver, a voltage meter, and the SolarEdge setup app. Setting the dip switches: The video explains how to set the dip switches to configure the maximum current to your circuit breaker. Turning on the AC power: The charger will perform a self-test and display "out of service" for 10 minutes. While waiting, you can scan the QR code to monitor the process using the SolarEdge app. Activating commissioning mode: This mode allows you to perform initial testing. To activate it, turn on dip switch number 8 and press the service button until you hear a beep. Testing the EV Charger: The video demonstrates how to use a voltage meter to test the charger gun. Deactivating commissioning mode: Once testing is complete, turn off dip switch number 8 and press the service button again. Pairing the charger with the inverter: Use the SolarEdge app to scan the QR code of the inverter and pair the charger. This enables Smart Energy control. Monitoring and registration: The video explains how the app will automatically monitor and register the EV charger. Please refer to the    • How To Connect The SolarEdge EV Charger | ...   for installation instructions prior to commissioning it. Introduction 0:00-0:20 Required tools 0:20-0:35 Setting the DIP switch 0:35-1:05 Turning on AC 1:05-1:55 Activating commissioning mode 1:55-2:40 Deactivating commissioning mode 2:40-2:56 Registering the EV Charger 2:56-3:41 Summary 3:41-4:01
