GEORG precisioncut TBA 1000 - Step-Lap Lamination Cutting Line

Description / Beschreibung (unten) Lamination line for efficient cutting of "step lap" core plates. Thanks to consistent minimisation of set-up times and high production speeds, the TBA 1000 delivers high production and throughput rates for efficient cutting of "Step Lap" core sheets. Main technical data: 100 to 1020 mm (standard width range), Decoiler(2 or 4 mandrels, Long arm decoiler, Capstan and coil car), Max speed 240 m/min. Tooling (all tools servo motor operated): V notch: 1 or 2, Hole punching (up to 4 fixed longitudinally, manual or CNC cross adjustable), Slot punching unit, Tip cutting shears, 2 fixed shears 45 and 45/90 or high speed swing shear, Stacking Systems: HS/T two level with pneumatic stopping system, DW/T two level, servo belts, side guides, and drawback system, STA 1-1 two level with servo belts and full length side guides, STA(2) two in-line stations with servo belts and full length side guides, STA 2-3 two level 5 station full sequence with servo belts and full length side guides, E stacker Datasheet: https://www.georg.com/fileadmin/downl... More information on our website: https://www.georg.com/northamerica/en... Deutsch: Transformatorenbandabschneideanlage zum effizienten Schneiden von „Step Lap"-Kernblechen. Dank konsequenter Rüstzeitenminimierung und hohen Produktionsgeschwindigkeiten liefern wir mit der TBA 1000 hohe Produktions- und Durchsatzleistungen zum effizienten Schneiden von „Step Lap"-Kernblechen. Datenblatt: https://www.georg.com/fileadmin/downl... Weiterführende Informationen auf unserer Website: https://www.georg.com/germany/de/prod...
