Multispan Process Indicator PI-38

Multispan Process Indicator PI-38 A detailed tutorial on the Multispan Process Indicator, model PI-38, covering everything from wiring to full configuration and testing. Learn how to correctly connect the auxiliary power supply and the various analog inputs (0-10V DC, 0-20mA, and 4-20mA) to the device. This video provides a step-by-step guide on accessing the configuration menu and setting essential parameters like: Input selection Decimal point placement Low/High range scaling Filter time Offset Signal low limit We demonstrate the practical scaling and testing for both the 4-20mA and 0-10V DC inputs using real-world examples, such as scaling for motor RPM and motor amperes. Chapters: 00:00:01 Introduction to Multispan PI-38 Process Indicator 00:00:11 Wiring Connections: Auxiliary Supply & Analog Input Terminals (3, 4, 5) 00:01:03 Accessing the Configuration Menu (Set & Side Arrow Key) 00:01:13 Setting Parameters for 4-20mA DC Input 00:01:42 Scaling Low and High Range (Example: 0 to 14000 RPM) 00:02:14 Setting Signal Low Limit (Lo indication) 00:02:36 Live Demonstration: Testing 4-20mA Input Scaling 00:03:48 Switching Connections to 0-10V DC Input 00:04:09 Configuring Parameters for 0-10V DC Input 00:04:33 Scaling High Range for Motor Amperes (Example: 0 to 45 Amps) 00:05:02 Live Demonstration: Testing 0-10V DC Input Scaling #Multispan #PI38 #ProcessIndicator #420mA #010VDC #AnalogInput #IndustrialAutomation #MultispanSupport #ProcessControl #WiringTutorial #ConfigurationGuide #SensorScaling
