Daewoo PUMA Series TT 2500 SY - GL turning lathe sub spindel C axis gantry loader MACH4METAL 6615 2 скачать в хорошем качестве

Daewoo PUMA Series TT 2500 SY - GL turning lathe sub spindel C axis gantry loader MACH4METAL 6615 2

https://mach4metal.com/en/machines/ch... CNC turning lathe DOOSAN - TT 2500 SY GL CNC lathe C + Y Axis and Sub spil MACH - ID 6516 Make: DOOSAN Type: TT 2500 SY GL Control: FANUC 18i-TB YOP: 2004 Hours: 18221 Gantry loaded Bar feeder Double chuck 250 mm Axis X1 / X2 / Z1 / Z2 / C1 / C2 / Y / B Axis Specifications US Standard Metric Max. turning Ø 390 mm X-Axis 255 mm Y-Axis 120(+60/-60) mm Z-Axis 800 mm B Axis 800 ° Spindle bore 76 mm Speedrange 3500 Rpm Spindle power 26 kW Subspindle speeds 4000 Rpm Subspindle power 26 kW ATC / revolver 12 Speed live tools 4000 Rpm Chip conveyor Yes Tool eye Yes Dimensions Length 4.000 mm Width 3.200 mm Height 2.300 mm Weight 15.500 kg Downloads https://mach4metal.com/en/doosan-tt-2... Gantry loaded Bar feeder Double chuck 250 mm Axis X1 / X2 / Z1 / Z2 / C1 / C2 / Y / B Axis Max. turning Ø: 390mm X-Axis: 255mm Y-Axis: 120(+60/-60) mm Z-Axis: 800mm B Axis: 800° Spindle bore: 76mm Speedrange: 3500Rpm Spindle power: 26kW Subspindle speeds:4000Rpm Subspindle power:26kW ATC / revolver: 12 Speed live tools:4000Rpm Chip conveyor: Yes Tool eye: Yes Length: 4.000 mm Width: 3.200 mm Height: 2.300 mm Weight: 15.500 kg Please Note: The information on this page has been obtained to the best of our ability and belief from, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
