MadCap+ 17/19 - Connections!!! (Naim preamp supply and Neurochrome Buffers)

How do we hook the silly things up? Also watch my other video, "Naim Preamp Connections Are WEIRD!!!" -    • Naim Preamp Connections Are WEIRD!!!   MadCap+ History ---------------------------- Part 1 - Introduction and Ideas for Layout -    • MadCap+ 1/19 - Introduction and Ideas for ...   Part 2 - Back Panel Connections -    • MadCap+ 2/19 - Back Panel Connections  (Na...   Part 3 - Mirror Layout -    • MadCap+ 3/19 - Mirror Layout  (Naim preamp...   Part 4 - Back Panel Drilling Templates -    • MadCap+ 4/19 - Back Panel Drilling Templat...   Part 5 - Back Panel Drilling Templates -    • MadCap+ 5/19 - Back Panel Populated (Naim ...   Part 6 - Base Plate Final Layout -    • MadCap+ 6/19 - Base Plate Final Layout (Na...   Part 7 - Base Plate WIP -    • MadCap+ 7/19 - Base Plate WIP (Naim preamp...   Part 8 - HackerCap Plan -    • MadCap+ 8/19 - HackerCap Plan (Naim preamp...   Part 9 - HackerCaps Done -    • MadCap+ 9/19 - HackerCaps Done (Naim pream...   Part 10 - Wiring Warzone -    • MadCap+ 10/19 - Wiring Warzone (Naim pream...   Part 11 - Audio Buffers Connected -    • MadCap+ 11/19 - Audio Buffers Connected (N...   Part 12 - Just Say NO! to Ground Loops -    • MadCap+ 12/19 - Just Say NO! to Ground Loo...   Part 13 - 2nd Buffer Power Supply -    • MadCap+ 13/19 - 2nd Buffer Power Supply (N...   Part 14 - Buffers Connected -    • MadCap+ 14/19 - Buffers Connected (Naim pr...   Part 15 - Shunt Regulators Soaking -    • MadCap+ 15/19 - Shunt Regulators Soaking (...   Part 16 - Transformer Buzz Experiment -    • MadCap+ 16/19 - Transformer Buzz Experimen...   Overview: ---------------- Provide a power supply and dual audio buffers for a Naim NAC282 Preamp (or 82, 202, 102, etc.), including: Supply two 5-pin outputs like a Naim HiCap, each with two +24VDC (4 total). Supply one 2-pin "Aviation" output of +18VDC, like a Naim NAPSC. Input XLR stereo source, and output stereo RCA, plus Naim 5-pin. Input Naim 4-pin preamp signal, and output stereo RCA. Parts List: ----------------- Avondale ASR2 Shunt Regulator - https://avondaleaudio.com/store/#!/AS... Avondale FWB2 Rectifier - https://avondaleaudio.com/store/#!/FW... Avondale SSM2 Soft Start Module - https://avondaleaudio.com/store/#!/SS... ...or... Neurochrome Intelligent Soft Start - https://neurochrome.com/products/inte... Neurochrome Universal Buffer - https://neurochrome.com/products/univ... Neurochrome Preamp Power Supply - https://neurochrome.com/products/prea... Hammond 185D24 Transformer - https://www.hammfg.com/part/185D24 Kemet 3300µF 63VDC Capacitor - https://search.kemet.com/download/spe... 0.1µF 50V PPS Bypass Capacitor Epcos 12µH 3A Choke - https://4donline.ihs.com/images/VipMa... PrehKeyTec 71430-250/0802 5-pin 240° DIN (Naim power supply for preamp) - https://www.farnell.com/datasheets/23... PrehKeyTec 71430-050/0800 5-pin 180° DIN (Naim source for preamp) - https://www.farnell.com/datasheets/23... PrehKeyTec 71430-040/0800 4-pin 216° DIN (Naim output to power amp) - https://www.farnell.com/datasheets/23... GX16-2 2-pin Aviation Screw Connector (Naim NAPSC) - https://a.co/d/ermitLT Modushop Pesante 2U/300mm Case - https://modushop.biz/site/index.php?r... Moon Audio Blue Dragon Cables - https://www.moon-audio.com/products/b...
