How to Configure an IPsec CyberSecure Communication with M580 | Schneider Electric Support

This video shows how to create a cyber secure Ethernet communication between the BMENOC0301/0311 and other devices, like applications running on a virtualized environment (OPC Server, SCADA, Historian, etc.). ►Learn More: http://spr.ly/SchneiderElectric/produ... ►How can I Reduce Vulnerability to Cyber Attacks: https://download.schneider-electric.c... EcoStruxure Control Expert version 14.1 Modicon M580 version 3.10 BMENOC0301 version 2.18 ►Windows Firewall Configuration Step 2: netsh advfirewall set global mainmode mmkeylifetime 2879min,0sess Step 3: netsh advfirewall set global mainmode mmsecmethods dh2048_variable Edit dh2048_variable in the command according to your Enable DH 2048 selection: unchecked: dhgroup2:aes128-sha256 checked: dhgroup14:aes128-sha256 Step 4: netsh advfirewall consec add rule name="BMENOC0301_rule_xyz" endpoint1=xxx.xxx.xxx.xxx/xx endpoint2=yyy.yyy.yyy.yyy/yy action=requireinrequireout description="DH2048&confidentiality_state" mode=transport enable=yes profile=public type=static protocol=any auth1=computerpsk auth1psk=YourPskGoesHere qmpfs=none qmsecmethods=confidentiality_variable Edit the command: BMENOC0301_rule_xyz: Modify to meet your application needs. xxx.xxx.xxx.xxx/xx: Use the IP address of the Control Expert host (PC or device). yyy.yyy.yyy.yyy/yy: Use the IP address of the BMENOC301/311 module DH2048&confidentiality_state: Modify this description to reflect the state of the check boxes (Enable DH 2048, Enable Confidentiality). YourPskGoesHere: Use the pre-shared key that is configured in the DTM. Edit confidentiality_variable according to your Enable Confidentiality selection: unchecked: ah:sha256+1440min checked: esp:sha256-aes128+1440min ►Click here to subscribe to Schneider Electric: https://www.youtube.com/c/schneiderel... Connect with Schneider Electric: ►Global Website: http://spr.ly/SchneiderElectric ►Discover our Services: http://spr.ly/SE-Services ►Visit our Blog: http://spr.ly/SE-Blog ►Job Opportunities: http://spr.ly/SE-Careers ►LinkedIn:   / schneider-electric   ►Facebook:   / schneiderelectric   ►Twitter:   / schneiderelec
