Terex Finlay 883+ Heavy Duty Screener

Engine: Tier 4F / Stage IV - Caterpillar C4.4 - 4 cylinder diesel engine developing 82kW (110 Hp) @ 2200 RPM Dual Power – 2 x IE3 electric motors c/w hydraulic gear pumps and electrical control panel allowing machine to run in either Diesel or Electric mode Feeder: Abrasion Resistant plate steel pan apron feeder with heavy duty chain drive Fixed Hopper Remote start stop of pan feeder Screenbox: Hydraulic raise for mesh changing (500mm) Both top and bottom decks 4.8m x 1.5m (16' x 5') Conveyors: 1200mm (48") wide O/S conveyor c/w chevron belt & skirting 800mm(32") wide chevron belt on middle grade conveyor with variable speed & thumper roller 800mm (32") wide plain belt on fines conveyor with variable speed and belt scraper Separate hydraulic drive for both transfer and fines conveyor Options: Radio remote control of tracks Extended fines & middle grade conveyors Impact bars full length of oversize conveyor Magnetic Drive drum on fines and/or Mid Grade Conveyor
