VITACCI ROVER 300 GAS GOLF CART UTV | EFI

Click Here to Buy: https://161powersports.com/product/ro... SPECIFICATIONS Model ROVER 300 EFI Dimensions Overall length 2888mm Overall width 1565mm Overall height 1844mm Seat height 784mm Wheelbase 1839mm Ground clearance 260mm Basic weight With oil and full fuel tank 425kg Final gear case oil Type Wet tank lubrication Quantity 1.6 L Fuel Type Unleaded gasoline only 91# or higher Fuel tank capacity 24L Transmission Transmission type Two speed one down Operation Manual Chassis Frame type Steel tube frame Caster angle 5.0 ° Tire Type Tubeless Size Front 24×12–8 Rear 24×12–8 Brakes System Front and rear unified Type Front Dual disc brake Type Rear Dual disc brake Operation Foot operation Suspension Front suspension Double A-arm Rear suspension Double A-arm Shock absorber Front shock absorber Coil spring / oil damper Rear shock absorber Coil spring / oil damper Wheel travel Front wheel travel 80 mm Rear wheel travel 60 mm Engine model 175MN Type 4-stroke, Single-Cylinder, Water cooled Cylinder diameter 75mm Piston stroke 65mm Compression ratio 10.8 :1 Displacement 287.2mL Spark plug CR8EA Maximum power 21Kw/8500r/min Maximum torque 26.5N.m/5500r/min Idle speed 1600± 100rpm Limited speed 40km/h Engine oil capacity 1600ml（ SAE15W-40） Gearbox oil capacity 1300ml(SAE 85W/140) Gear ratio F:4.93,R:9.74 Magneto power 400W@4000rpm
