Calgary Flames Concept Arena (Version 6 SaddlePlex)

Instagram:   / noahb_creations   Renderings: http://imgur.com/a/ekfrl Download: https://3dwarehouse.sketchup.com/soci... Previous Arenas:    • Concept Arenas   The SaddlePlex Features a design retaining the Iconic saddle roof shape, the Largest capacity in the NHL, a lower bowl that seats more than 12900, two open concourses, two clubs with a combined 1300 loge style seats, and a unique skylounge looking directly down on the ice. SaddlePlex Statistics: 16 large mens washrooms, 16 large womens washrooms, 4 sets of escalators, 4 elevators, 12 sets of stairs, 78 luxury suites with a total capacity of 1992, and a bigger scoreboard than rogers place. Lower bowl seating: 12903, middle bowl seating: 3568, 300 level rows one through nine seating: 3440, nosebleeds (blue chairs) seating: 3528, loge seating: 1332, skylounge restaurant capacity: 248. Total fan capacity before nosebleeds: 23483. Grand Total Fan Capacity of 27011. This design reaps all the benefits of the hyperbolic paraboloid saddle shape without any of the drawbacks regarding concourse design, or convenience. Benefits such as significantly reduced energy consumption due to the comparatively low volume inside the arena, the majority of fan seating maintaining the desirable centre ice position, or the fact that the roof design encourages the use of the unique gondola style skylonge make this a unique and uncompromising design. More on the hyperbolic paraboloid saddle shape can be found here: http://www.nrcresearchpress.com/doi/p... Music: https://itunes.apple.com/ca/album/evo... Scoreboard Picture: http://www.cbssports.com/nhl/news/vid... This project has no affiliation with the NHL, Calgary Flames, Calgary Sports and Entertainment Corporation, or CalgaryNEXT. Created by Noah Brodeur
