How to measure AC voltage with Multimeter ?

How to measure AC voltage (Alternating current) with Multimeter? Multimeter setting: Insert Black probe at common Jack and Red probe at Voltage input terminal jack, Identify the A/C voltage symbol on the dial and turn the dial to that position, The multimeter powers up and the A/C voltage symbol appears on the display. Most multimeters power up in Auto range mode, It can automatically select the best range based on the voltage present on the test probes, For a manual range multimeter always set the next highest range for the measurement. Follow all safety procedures before taking measurement, Connect test leads to the circuit, Black lead first and Red lead second, we can see the A/C voltage reading on the display. A/C voltage doesn't have polarity, So the polarity of the test probes doesn't matter here. Manual Range: If we press the Range button, The meter enters into Manual range mode, and now the user needs to select the best range for his measurement. It is to be noted that the higher the range we select the lower the accuracy in reading. The auto range can be restored by continuously pressing the Range button for more than 2 seconds. Always pay attention to the characters in the display. If small 'm' appears on the display, that means multimeter displaying millivolts. Timestamps for various topics covered in this video are as follows: 0:18 Multimeter setting for A/C voltage measurement, 0:43 Identifying symbols on the display, 1:00 Safety precautions before taking measurements, 1:14 Taking A/C voltage measurement, 1:33 Auto range vs Manual range, 2:45 Manual range resolution, 3:41 Manual range multimeter setting. The links for related videos: 1) Alternating current and Direct current    • AC and DC, Alternating current and Direct ...   2) How to test FET    • Видео   3) How to test Transistor    • Видео   4) How to test MOSFET    • How To Test MOSFET?   5) How to test Diode    • How to Test a Diode?   6) True RMS vs Standard multimeter    • True RMS Vs Standard Multimeter   This video is helpful for students and working professionals, #How to measure ac voltage #How do you measure AC voltage in a circuit? #How to Measure AC Voltage Using a Multimeter #Measuring Voltage - How to Use a Multimeter #How can a multimeter measure AC voltage? #how to check 240 voltage with a multimeter #multimeter ac voltage symbol #how to measure ac current Music credits: Ben sounds Please SUBSCRIBE to my YouTube channel. "Keep Learning and Keep Growing".
