Kitamura Mytrunnion 5 Axis Vertical Machining Center 20000 RPM CNC Milli- MachineStation # 1916

Please Call us at 909-919-9600 or Visit us at http://www.MachineStation.us for more details., MachineStation, 4520 Danito Court, Chino, CA 91710 https://www.machinestation.us/product... Make: KITAMURA Model No.: MyTrunnion Year of Manufacture: 2003 Serial # 10003 Condition: Very Good Cutting Hours: 7216 Cutting Aluminium and Brass Only All specifications are approximations, and are subject to verification. “Rare to find Machine On our Floor now, fully powered / tested & is in Great working condition.” KITAMURA MYTRUNNION Features: Fanuc 16iM CNC Control Simultaneous 5 Axis Cutting 20,000 RPM High Precision Spindle Coolant through Spindle 100 Tools High Speed Tool Changer ( Optional ) Glass Scales on the Axis PCMCIA Card Slot 128 MB Memory Spindle Chiller Spindle Orientation Helical Interpolation Rigid Tapping Absolute Incremental Programming Fast Rapid Traverse Rate Flood coolant with large separate coolant tank Chip Conveyor Work light Books and Manuals. KITAMURA MYTRUNNION Specifications: Travels: X Axis: 32.3″ Y Axis: 29.3″ Z Axis: 19.6″ A Axis: 150° ( Table Tilt ) C Axis: 360° ( Table Rotate ) Table: Length: 24.8″ Width: 19.7″ Max Weight on Table: 880 lbs T-Slot : 0.7″ X 3 Slots Table to Spindle Nose: 3.9″ – 23.6″ Spindle: Taper Size: 40 Speed Range: 20 – 20,000 RPM Spindle Power: 20 HP Feed rates: Rapid X & Y : 1968 Inch Per Minute Rapid Z : 984 Inch Per Minute Rapid A : 2000 Degree Per Minute Rapid C : 6000 Degree Per Minute Cutting Feedrate: 984 Inch Per Minute Tool changer: Capacity: 100 Tools ( Optional ) Taper: 40 Max Tool Size: 5.91″ X 11.8″ Max Tool Weight: 22 lbs. Tool Change Time: 1.7 Second General: Air Required: 80 psi, 4 scfm Power: 45kva / 205-220v / 3-Phase Overall Dimensions: ??″ High Weight: 38,000 lbs KITAMURA MYTRUNNION Comes as shown in pictures..Make: KITAMURA Model No.: MyTrunnion Year of Manufacture: 2003 Serial # 10003 Condition: Very Good Cutting Hours: 7216 Cutting Aluminium and Brass Only All specifications are approximations, and are subject to verification. “Rare to find Machine On our Floor now, fully powered / tested & is in Great working condition.” KITAMURA MYTRUNNION Features: Fanuc 16iM CNC Control Simultaneous 5 Axis Cutting 20,000 RPM High Precision Spindle Coolant through Spindle 100 Tools High Speed Tool Changer ( Optional ) Glass Scales on the Axis PCMCIA Card Slot 128 MB Memory Spindle Chiller Spindle Orientation Helical Interpolation Rigid Tapping Absolute Incremental Programming Fast Rapid Traverse Rate Flood coolant with large separate coolant tank Chip Conveyor Work light Books and Manuals. KITAMURA MYTRUNNION Specifications: Travels: X Axis: 32.3″ Y Axis: 29.3″ Z Axis: 19.6″ A Axis: 150° ( Table Tilt ) C Axis: 360° ( Table Rotate ) Table: Length: 24.8″ Width: 19.7″ Max Weight on Table: 880 lbs T-Slot : 0.7″ X 3 Slots Table to Spindle Nose: 3.9″ – 23.6″ Spindle: Taper Size: 40 Speed Range: 20 – 20,000 RPM Spindle Power: 20 HP Feed rates: Rapid X & Y : 1968 Inch Per Minute Rapid Z : 984 Inch Per Minute Rapid A : 2000 Degree Per Minute Rapid C : 6000 Degree Per Minute Cutting Feedrate: 984 Inch Per Minute Tool changer: Capacity: 100 Tools ( Optional ) Taper: 40 Max Tool Size: 5.91″ X 11.8″ Max Tool Weight: 22 lbs. Tool Change Time: 1.7 Second General: Air Required: 80 psi, 4 scfm Power: 45kva / 205-220v / 3-Phase Overall Dimensions: ??″ High Weight: 38,000 lbs KITAMURA MYTRUNNION Comes as shown in pictures
