Mastercam Lathe Face Groove Angular Groove Tool Path

Hello Everyone, Subscribe for upcoming series to learn Mastercam software. These videos are available in both Hindi and English for your convenience. Mastercam Training video made to those working in CNC ,CAD /CAM area. Groove Toolpaths Groove toolpaths are useful for machining indented or recessed areas that are not otherwise machinable by roughing toolpaths or tools. Mastercam can machine many types of grooves based on the location of one or more corner points, without requiring you to create or chain geometry. You can also use chained geometry if you prefer, or to specify intricate groove contours. You can machine several grooves in a single operation, even if their geometry never connects. Mastercam also integrates roughing and finishing passes, each with separate parameters, in a single operation. Groove toolpaths are typically created in several stages: Use the Grooving Options dialog box to tell Mastercam how the grooves will be identified (corner point, chained geometry, etc.). Then, use the Lathe Groove dialog box to select a tool and enter the toolpath parameters. Separate tabs let you define the following: Shape, angle, and orientation (for example, ID, OD, face) of the groove, including automatic chamfers/radii on corners Roughing parameters, including options for pecking and depth cuts. You can choose to omit the roughing pass and just create a finishing operation. Finishing parameters. You can choose to omit the finishing pass and just create a roughing operation. In addition to the standard groove toolpaths, which include all the grooving capabilities described above, Mastercam also includes canned groove toolpaths for less-demanding applications. To begin creating a groove toolpath, choose Lathe, Turning, General, Groove. Contact us for personal Training and Mastercam Software requirement (For both Industrial and Educational) . sekar1971@gmail.com http://pragathicamtech.com/ LIKE||SHARE|| SUBSCRIBE
