Carvera Air 4-Axis NATO Rail Machining | High-Precision Centering

$100 / €100 OFF Coupon for Carvera or Carvera Air Code: cinetronix Makera Official Store (non-affiliate) https://www.makera.com Affiliate Link (supports the channel at no extra cost) https://makerainc.sjv.io/c/6936694/19... I purchased this Carvera Air with my own funds. This video is not sponsored. ________________________________________________________________________ This video shows the process of machining a custom NATO rail for the Sony FX3 / FX30 XLR Handle Unit (XLR-H1) using 4-axis machining on the Makera Carvera Air. With the 4th Axis Module, the entire part can be completed in a single setup without flipping the stock. Accurate 4-axis machining requires proper calibration. Even a small offset in the A-axis machine zero can cause misalignment between the two sides, resulting in steps on the profile and holes. I’m sharing my calibration workflow using the excellent, community-driven macros available in Carvera Controller Community and a 3D touch probe, and also how I quickly and accurately center and chuck a flat plate stock material that isn’t round or square using a dedicated jig. ________________________________________________________________________ TIMESTAMPS 00:00 Intro 00:13 4th Axis Module Calibration 02:17 4th Axis Centering Jig (Chuck & Tailstock) 02:58 A-Axis Zero Set 03:35 Fusion 360 4th Axis Simulation 05:05 WCS Setup 05:16 T1 Ø6 mm — Face 06:13 T1 Ø6 mm — Bore / Circular 06:20 T2 Ø4 mm — Bore / Circular 06:41 T3 Ø3.175 mm — Bore / Circular 07:05 T4 Ø2 mm — Bore / Circular 07:40 T5 Ø4.88 mm (1/4"-20 UNC) — Thread 07:55 T6 Ø6.7 mm (3/8"-16 UNC) — Thread 08:07 T7 Ø4 mm Ball End Mill — Rotary Parallel 09:10 T2 Ø4 mm — 2D Contour 09:35 T8 Ø4 mm 45° Chamfer Mill — Trace / 2D Chamfer / Deburr 09:56 T9 Ø1 mm Ball End Mill — Deburr 10:24 T2 Ø4 mm — 2D Contour 11:28 Accuracy Check ________________________________________________________________________ PROJECT DETAILS Machine: Makera Carvera Air (Desktop CNC) Material: 6061 Aluminum https://s.click.aliexpress.com/e/_c2v... Tools: T1 Ø6 mm https://global.makera.com/products/sp... T2 Ø4 mm https://global.makera.com/products/sp... T3 Ø3.175 mm https://global.makera.com/products/sp... T4 Ø2 mm https://global.makera.com/products/sp... T5 Ø4.88 mm (1/4"-20 UNC) T6 Ø6.7 mm (3/8"-16 UNC) https://s.click.aliexpress.com/e/_c3c... T7 Ø4 mm Ball End Mill https://global.makera.com/products/tw... T8 Ø4 mm 45° Chamfer Mill https://global.makera.com/products/ch... T9 Ø1 mm Ball End Mill https://global.makera.com/products/tw... 8 mm Shank Collet https://s.click.aliexpress.com/e/_c4M... 3D Touch Probe https://s.click.aliexpress.com/e/_c3d... Digital Angle Gauge https://s.click.aliexpress.com/e/_c3I... GO/NO-GO Thread Plug Gage (Class 2B) https://s.click.aliexpress.com/e/_c3J... K02-50 Chuck Stopper for Makera Carvera Air 4-Axis https://makerworld.com/ja/models/2434... Software: Fusion 360 (CAD/CAM) Carvera Controller Community https://carvera-community.gitbook.io/... ________________________________________________________________________ NOTE All toolpaths and cutting parameters shown in this video are experimental. Results may vary depending on tools, materials, machine condition, and setup. They are not intended as general recommendations. Always follow proper safety procedures when operating CNC equipment. ________________________________________________________________________ MORE CONTENT For more machining tests, camera-rig components, and behind-the-scenes updates:   / cinetronix   ________________________________________________________________________ Some links used in this description may be affiliate links. #CarveraAir #MakeraZ1 #4axismachining #ThreadMilling #AluminumMachining #Carvera
