KiCad 3.0 - Schematic Creation with EEschema - Getting To Blinky KiCad Tutorial - Part 3

This video creates a schematic using the symbol created in Part 2 of the Getting To Blinky tutorial (   • KiCad 3.0 - Symbol Creation with the Compo...  ). At the end of this video you will have a full schematic that can be used to create a layout of the final PCB. For more information about Contextual Electronics http://contextualelectronics.com KiCad is available here: http://www.kicad-pcb.org/display/KICA... Discuss the program here: https://forum.kicad.info "Getting To Blinky" is a multi-part series that shows you all the steps necessary to move your project off the screen or breadboard and onto a PCB. The videos will show you how to use KiCad, a cross-platform and open source piece of software. The finished product of this video series will be a PCB you can purchase and build. Oh, and it will blink.
